Raft Detailed Explanation

Introduction

Consensus algorithms can enforce a collection of machines to maintain same total order of messages or inputs to ensure their state consistency. Paxos [2] [3] once dominated the discussion of consensus algorithm, lots of the consensus implementations are based on Paxos or influenced by it.

However, Paxos is quite difficult to understand, thus, Ongaro et al posted a brand new consensus algorithm that has better understandability and more practical application scenarios: Raft.

Raft applied specific techniques to improve understandability, including decomposition and state space reduction. Raft is similar in many ways to existing consensus algorithms (e.g. Viewstamped Replication [29, 22]), but it has several novel features:

• Strong Leader: Log entries only flow from the leader to other servers
• Leader election: Raft uses randomized timers on leader election to avoid endless loop.
• Membership changes (Reconfiguration): Cluster can continue operating normally during configuration changes.

The Raft Consensus Algorithm

1 Overview

Raft decomposes the consensus problem into three relatively independent subproblems, which are discussed in the subsections that follow:

• Leader election: Elect new leader when an existing leader fails
• Log replication: The leader accept request from clients and replicate them across the cluster
• Safety: The key safety properties for Raft are listed below:
  • Election Safety: At most one leader can be elected in a given term.
  • Leader Append-Only: A leader never overwrites or deletes entries in its own log, it only appends new entries.
  • Log Matching: If two logs contain an entry with same index and term number, then the logs are identical in all entries up through the given index.
  • Leader Completeness: If a log entry is committed in a given term, then that entry will be present in the logs of subsequent leaders with higher terms, which means that a committed entry should never be overwritten or lost by any leader after the commitment.
  • State Machine Safety: If a server has applied a log entry at a given index to its state machine, no other server will ever apply a different log entry for the same index.

1.1 Replicated State Machines

Replicated state machines are typically implemented with a replicated Write-Ahead Log (WAL), in Figure 1. Each server stores a log that contains a series of commands, state machine will execute them in log order.

Keeping the replicated logs consistent is the job of the consensus algorithm. It ensure that all replicated logs eventually contains same commands in the same order, even if some servers fail.

2 Raft Basics

Raft has three main roles: leader, follower, candidate.

• Leader is responsible for handling clients’ requests, and the requests sent to follower will be redirected to leader. When the leader receives a request, it will append the request to its log and send messages to inform other servers to append this request to their logs.

• Followers are passive, they only respond requests, don’t send request themselves.

• Candidate is a server that is currently running for the leader position.

In all the normal case, there will be at most one leader, and others are followers or candidates.

Raft servers communicate with Remote Procedure Calls (RPCs), and here are required RPC types:

• AppendEntries: Leader send this to inform follower to append entry or as heartbeat.
• RequestVote: Candidate send this to request votes.

Raft uses heartbeat mechanism to detect the liveness and trigger leader election. Leader will send periodic heartbeats (AppendEntries that carry no log entries) to all followers to indicate its liveness.

Raft divide time into terms, numbered with consecutive integer, each term begin with an election, a term can end with no leader if no candidate get enough votes.

2.1 States and Storage

1. States on persistent storage (disk) for all server:

   • currentTerm: Highest term the server has seen. Initialized to 0, and increase monotonically.
   • votedFor: Candidate ID that voted for in the current term. Initialized to null.
   • log[]: Log entries, each entry contains a command and term of the leader when creates this entry.

   In some implementations like braft [4], these states also have a copy in memory for efficient access.

2. States on volatile storage (memory) for all server:

   • commitIndex: Index of highest log entry known to be committed. Initialized to 0.
   • lastApplied: Index of highest log entry applied to state machine. Initialized to 0.

3. States on volatile storage (memory) for leaders:

   • nextIndex[]: Array that records index of the next log entry to send to for each server. Initialized to the leader’s last log index +1.
   • matchIndex[]: Array that records index of the highest log entry known to be replicated for each server. Initialized to 0.

2.2 States Transition

currentTerm

The currentTerm will be attached to every messages sent between servers. Server rejects the request with a term that is smaller than (stale) its currentTerm. The server with stale term will update its currentTerm with the received one, if this server is leader or candidate, it turns to a follower.

Besides, when a follower triggers a timeout and start an election, it will increase the currentTerm by 1.

votedFor

The votedFor will be set to the candidate ID if the server grant a vote to a validate candidate, and in each time the currentTerm increases, the votedFor will be reset to null.

log[]

3 Leader Election

Once a follower triggers a election, it will increment its currentTerm and turn to candidate, vote for itself and send RequestVote to other servers, each server can vote at most one candidate in a given term (including the vote to itself), on a first-come-first-served basis (more restriction will be introduced later). A candidate wins an election if it receives votes from a majority of the servers in the same term.

A candidate continues in this state until one of three things happens:

• It wins the election
• Another server wins the election
• A period of time goes by with no winner

3.1 Candidate Wins

The candidate receives majority vote in same term, it turns to leader, send heartbeat to all servers (followers).

3.2 Another Server Wins

The candidate receives heartbeat with term not smaller than its own, it turns to follower.

3.3 No Server Wins

In a period of time, no candidate gets majority votes, triggers election timeout, then a new election will be started by incrementing its term and initiating another round of RequestVote. However, without extra measures, split votes could repeat indefinitely. Thus Raft uses randomized election timeouts to ensure that split votes are rare. Which means election timeouts are chosen randomly, to avoid candidates send RequestVote at the same time.

The server role transition diagram is shown in the Figure 2.

4 Log Replication

For a log replication process:

1. The client will first send a request with command to one of the server, which will eventually be redirected to leader.
2. The leader will append this entry to its log, and send AppendEntries to other servers, followers will respond to leader when it has append this entry to its log.
3. If entry is safely replicated in majority of the cluster, leader will apply this command to state machine and return to client.

If follower did not respond, leader will retry indefinitely even after it has return to client.

The overview of replicated logs are shown in Figure 3, where entries are listed with index, and each entry include a term number and its command.

An entry is considered to be committed once the leader that created the entry has replicated it on a majority of the servers. This also commits all preceding entries in the leader’s log, including entries created by previous leaders. The leader keeps track of the highest index it knows to be committed, and it includes that index in future AppendEntries (including heartbeats) so that the other servers eventually find out.

Once a follower learns that a log entry is committed, it applies the entry to its local state machine (in log order).

If no rollback attacks happen, Raft should ensures that (Log Matching):

• If two entries in different logs have the same index and term, then they store the same command.
• If two entries in different logs have the same index and term, then the logs are identical in all preceding entries.

Therefore, for higher safety guarentee, when sending an AppendEntries to replicate a new entry, the leader includes the index and term of the entry in its log that immediately precedes this entry. If the follower does not find an entry in its log with the same index and term, then it refuses the new entry.

When a new leader is elected, it may occurs that leader and followers have inconsistent logs, in this case, the leader’s log shall prevail. To bring a follower’s log into consistency with its own, the leader must find the latest log entry where the two logs agree, delete any entries in the follower’s log after that point, and send the follower all of the leader’s entries after that point.

Leader record this index for every followers in an array nextIndex[]. When a leader first comes to power, it initializes all nextIndex values to the index just after the last log (it will be 9 in Figure 3). If a follower’s log is inconsistent with the leader’s, the consistency check will fail in the next AppendEntries. After a rejection, the leader decrements this follower’s nextIndex and retries the AppendEntries.

5 Safety

The previous sections described how Raft elects leaders and replicates log entries. However, the mechanisms described so far are not quite sufficient to ensure that each state machine executes the same commands in the same order. For example, a follower might be unavailable while the leader commits several log entries, then it could be elected as leader and overwrite these entries with new ones. This section completes the Raft algorithm by adding a restriction on which servers may be elected leader.

5.1 Election Restriction

Unlike VR, transmitting the necessary entries to new leader, Raft’s log entries only flow in one direction: from leaders to followers, and leaders never overwrite existing entries in their logs.

Raft uses voting process to prevent a candidate from winning an election unless it contains all committed entries. The RequestVote implements this restriction: the RPC includes information about the candidate’s log, and the voter denies its vote if its own log is more up-to-date than that of the candidate.

Raft determines which of two logs is more up-to-date by comparing the index and term of the last entries in the logs. If the logs have last entries with different terms, then the log with the later term is more up-to-date. If the logs end with the same term, then whichever log is longer is more up-to-date.

5.2 Committing Entries From Previous Terms

Raft never commits log entries from previous terms by counting replicas. Only log entries from the leader’s current term are committed by counting replicas; once an entry from the current term has been committed in this way, then all prior entries are committed indirectly because of the Log Matching Property.

For the reason why leader can only commit entry in its own term, Figure 4 shows an example:

(for simplicity, entry is indicated as $E_{<index,\ term>}$)

In (a), S1 is elected as leader and append $E_{2,\ 2}$, and if only S2 replicated $E_{2,\ 2}$.

Then go to (b), S1 crashes, S5 can be elected as leader with vote from S3, S4, S5, then append $E_{2,\ 3}$.

When in (c), S5 crashes with no success replication, S1 restarts and is elected as leader with vote from S1-S4, then S1 will continue to replicated $E_{2,\ 2}$. At this time, $E_{2,\ 2}$ is replicated on a majority of the servers. However, if $E_{2,\ 2}$ is committed here and a election is triggered, S5 have the chance to win the election since it has an entry with larger term.

Then it will turn to (d), where S5 overwrite the “committed” entry $E_{2,\ 2}$. Thus, a leader should not commit the entry that is not appended in the current term even if it is replicated on a majority of the servers.

Only comes to (e), when S1 append $E_{3,\ 4}$ in its current term and commit it, $E_{2,\ 2}$ can be considered as committed.

5.3 Safety Argument

Given the complete Raft algorithm, this section provides some formal proof of safety.

5.3.1 Proof of Leader Completeness Property

Leader Completeness Property states that if a log entry is committed in a given term, then that entry will be present in the logs of the leaders for all higher terms.

Let’s assume that the Leader Completeness Property does not hold, then prove a contradiction.

Suppose the leader for term $T$ ($leader_T$) commits a log entry from its term, but that log entry is not stored by the leader of some future term. Consider the smallest term $U$ > $T$ whose leader ($leader_U$) does not store the entry.

1. The committed entry must have been absent from $leader_U$’s log at its election (leaders never delete or overwrite entries).
2. $leader_T$ replicated the entry on a majority, and $leader_U$ received votes from a majority. Thus, at least one server (“the voter”) both accepted the entry from $leader_T$ and voted for $leader_U$.
3. The voter must have accepted the committed entry from $leader_T$ before voting for $leader_U$, since if voter votes first, its currentTerm will be larger than $leader_T$ and will reject its request.
4. The voter granted its vote to $leader_U$, so $leader_U$’s log must have been as up-to-date as the voter’s. This only comes in two way:
5. First, if the voter and $leader_U$ share the same last log term, then $leader_U$’s log must have been at least as long as the voter’s, so its log should contained every entry in the voter’s log. Comes to contradiction.
6. Otherwise, $leader_U$’s last log term $L$ must be larger than the voter’s (at least $T$), let’s say $T<L<U$. However, the earlier leader in term $L$ that created $leader_U$’s last log entry must have contained the committed entry in its log, since we assume $U$ is the smallest term whose leader does not store the entry. Another contradiction.

5.3.2 Proof of State Machine Safety Property

State Machine Safety Property states that if a server has applied a log entry at a given index to its state machine, no other server will ever apply a different log entry for the same index.

1. At the time a server applies a log entry to its state machine, its log must be identical to the leader’s log up through that entry and the entry must be committed.
2. Now consider in some term that a server applies a given log index.
3. The Log Completeness Property guarantees that the leaders for all higher terms will store that same log entry, so servers that apply the index in later terms will apply the same value.

6 Follower and Candidate Crashes

Above only focus on leader failures. Follower and candidate crashes are much simpler to handle. If a follower or candidate crashes, then future RequestVote and AppendEntries RPCs sent to it will fail. Raft handles these failures by retrying indefinitely. If a server crashes after completing an RPC but before responding, then it will receive the same RPC again after it restarts. Raft RPCs are idempotent, so this causes no harm. For example, if a follower receives an AppendEntries request that includes log entries already present in its log, it ignores those entries in the new request.

7 Timing and Availability

To ensure availability, Raft will be able to elect and maintain a steady leader as long as the system satisfies the following timing requirement:

$broadcastTime ≪ electionTimeout ≪ MTBF$

where MTBF is the average time between failures for a single server.

8 Cluster Membership Changes

TODO

9 Log Compaction

Although servers normally take snapshots independently, the leader must occasionally send snapshots to followers that lag behind. This happens when the leader has already discarded the next log entry that it needs to send to a follower.

10 Client Interaction

TODO

References

[1] Ongaro, D., & Ousterhout, J. (2014). In search of an understandable consensus algorithm. In 2014 USENIX annual technical conference (USENIX ATC 14) (pp. 305-319).
